Description
SKU: ATE006
Vgate vLinker FD+ V2.2 wifi Version For Ford Support Android/IOS ELM327 OBD Adapter
Vgate FD+ Professional Refresh Hidden Scanner Perfectly Compatible With FORscan For Ford
13+ DETECTION FUNCTION:
1. Automatically lock
2. Speeding reminder
3. Emergency brake flashing lights
4. Lock the car and whistle
5. Xenon lamp mode
6. One-click skylight
7. Tire pressure monitoring
8. Snowflake logo
9. Cruise function
10. Compass
11. Average (instantaneous) fuel consumption
12.ECO energy saving mode
13. Steering power adjustment
Vqate vlinker FD+ Professionally Suitable for Forscan:
Support Programming And Diagnostic For Ford
Read / Clear
EngineDTC
Adiust Parameters
Refresh Parameters
Hidden Function Activated
Read Data Stream
Support Protocols
Multiple protocols:
–15 ELM format protocols;
— 23 STN format protocols;
— Up to 64 user-defined protocols.
OBDII 5 standard protocols:
— SAE J1850 VPW
— SAE J1850 PWM
— ISO 9141-2
— ISO 14230-4
— ISO 15765-4 CAN
Additionalprotocols:
— SAE J1939 CAN
— ISO 11898 (raw CAN)
–Medium Speed(MS CAN)
Theseprotocolscover almost 99% of the OBDII Cars on the market
Rich instruction set, compatible with more APP software:
— Fully compatible with ELM’s AT command set;
— Fully compatible with STN’s ST command set;
–39 VT macro commands, some instructions are equivalent to the effect of several AT and ST instructions, simplifying the communication steps.
— Compatible with ELM and STN power management solutions.
— Support for instructions, UART silence, battery low voltage, OBD bus silence, etc. Up to 5 ways to go to sleep;
— Support UART active, battery voltage drop, OBD bus active, key, etc. Up to 5 ways to wake up from sleep mode.
— Device sleep power consumption is less than 2 mA.
— OBD request byte up to 48 bytes, can meet the needs of some special long framecommunication.
— UART data buffer up to 2K bytes, baudrate increased to 230.4Kbps.
— 256-byte storage unit
— More than 100,000 erasable times
— Read and write operations on any unit in the storage area by using the VT command
— Mix ID Sending” mode of CAN protocol.
— Optional formatted send data according to protocol
— Multiple WM sequence settings
— Support AT command to manually set WM sequence
— Support for specifying a protocol or a full protocol-wide temporary WM sequence
— Support for a permanent link between a protocol and a private WM sequence
— Secure bootloader for easy firmware updates
Package list:
1 x Vgate vLinker WIFI
1 x User manual
